Briggs & Stratton 100000 - 19Z999 Series 170400 to 170499 OEM Parts Diagram for Key Panel

#	Description	Price	Qty
189	Lockwasher, Zinc Pl 90366 Ships in 1 to 2 days	~~$2.79~~ $2.57	Add
284A	Screw, Hex Head Tap (10-32 X 3/8) 93572 Ships in 1 to 2 days	~~$3.89~~ $3.58	Add
478	Kit-Panel 395408	Unavailable
501	Regulator \| (10, 13, or 16 Amp, Depending on Size of Flywheel Magnets) 845907 Ships in 1 to 2 days	~~$55.99~~ $46.01	Add
526	Screw, Tapping Hex 93343 Ships in 1 to 2 days	~~$2.99~~ $2.75	Add
561	Nut, Hex (1/4-20) 92278 Ships in 1 to 2 days	~~$4.09~~ $3.76	Add
575A	Switch-Starting 692303 Ships in 1 to 2 days	~~$59.99~~ $55.25	Add
578	Wire-Starter Switch 392683 Ships in 1 to 2 days	~~$9.49~~ $8.74	Add
605	Bracket-Regulator 222934 Ships in 1 to 2 days	~~$19.59~~ $18.04	Add
664	Screw-Hex (1/4-20 X 3/4) 93415 Ships in 1 to 2 days	~~$6.39~~ $5.88	Add
795	Switch-Toggle 496590 Ships in 1 to 2 days	~~$14.29~~ $13.16	Add
826	Wire Assembly \| (Starter Switch to Ground Wire Terminal) 690647 Ships in 1 to 2 days	~~$14.69~~ $13.53	Add
840	Panel Kit (Toggle Switch) 395408	Unavailable
840	Panel Kit (Key Switch) 395409 Ships in 1 to 2 days	~~$82.99~~ $76.43	Add
841	Clamp-Regulator 393514 Ships in 1 to 2 days	~~$18.39~~ $16.93	Add
944	Screw, Hex Flange H (For 3-5/8in. Housing Length) 94003 Ships in 1 to 2 days	~~$3.59~~ $3.30	Add
945	Bracket-Starter Motor 692132 Ships in 1 to 2 days	~~$9.69~~ $8.92	Add

Briggs & Stratton 170432-2354-01 Key Panel Diagram
